GigaDevice/GD32E230F8P6TR/TSSOP-20

ARM Cortex-M23 32-bit microcontroller -MCU chip

Product Description

       The GD32E230xx device belongs to the connectivity line of GD32 MCU Family. It is a new32-bit general-purpose  microcontroller based on the ARM® Cortex®-M23 coreThe Cortex-M23 processor is an energy-efficient processor with a very low gate count. It is intended to be used for microcontroller and deeply embedded applications that require an area-optimized processor. The processor delivers high energy efficiency through a small but powerful instruction set and extensively optimized design, providing high-end processing hardware including a single-cycle multiplier and a 17-cycle divider.

        The GD32E230xx device incorporates the ARM® Cortex®-M3 32-bit processor core operating at 72 MHz frequency with Flash accesses 0 to 2 wait states to obtain maximum efficiency. It provides up to 64 KB  embedded Flash memory and up to 8 KB SRAM memory.  An extensive range of enhanced I/Os and peripherals connected to two APB buses. The devices offer one 12-bit  ADC and one comparator, up to five general 16-bit timers, a basic timer, a PWM advanced timer, as well as standard and advanced communication interfaces: up to two SPIs, two I²Cs, two USARTs, and an I²S.

        The device operates from a 1.8 to 3.6 V power supply and available in -40 to +85°c temperature range. Several powers saving modes provide the flexibility for maximum optimization between wakeup latency and power consumption,  an especially important consideration in low power applications.

         The above features make the GD32E230xx devices suitable for a wide range of applications,  especially in areas such as industrial control, motor drives, user interface, power monitor and alarm systems, consumer and handheld equipment, gaming and GPS, E-bike and so on.

Electrical characteristics

           The maximum ratings are the limits to which the device can be subjected without permanently damaging the device. Note that the device is not guaranteed to operate properly at the maximum ratings. Exposure to the absolute maximum rating conditions for extended periods may affect device reliability.

Absolute maximum ratings
