Human Body Sensing Module, PIR Module, Infrared Module, Pyroelectric Human Body Infrared Sensor, Imported PM-6 Mini

Pyroelectric human body infrared sensor module

Imported optical probe, with a larger sensing window, is more stable and reliable

Model: PM-6
Sensing distance: 0-5 meters, output high level,H=3.3V,L=0V
Power supply DC: 3.3V-12V
Static current: 20uA

Purpose

    Human body sensor lights, alarms, security systems, access control cameras as needed, automatic equipment for agriculture, forestry and mining, etc.
    This module features high sensitivity, fast response speed, low static power consumption, compact size, and easy installation. The lens is already installed and the header pins are soldered. Once equipped with a power supply, it can be used without any debugging.
