DSO138 Oscilloscope Production Kit Electronic Learning Kit Handheld Pocket Oscilloscope DIY

DSO138 Oscilloscope Manufacturing Kit

Features of the DSO138 Oscilloscope manufacturing kit:

 1. Oriented towards electronic production training, the instruction materials are complete and detailed, including circuit diagrams, production guidance, usage instructions, troubleshooting methods, etc., with a high success rate of production.

 2. There are various types of components, which are suitable for students to train in component identification, through-hole component soldering, and surface mount component soldering.

 3. A practical tool can be obtained simultaneously during the production process, which can be used for audio and video synchronization, low-frequency switching power supply, infrared receiving and transmitting, etc.

 4 Effective observation and measurement of signal waveforms in multiple situations can increase learning interest and improve learning outcomes.

 5. The kit adopts an ARM Cortex-M3 processor (STM32F103C8) and includes a 2.4-inch color TFT display, which can be used as an ARM development test board.

6. The circuit is simple, reliable and inexpensive.

DSO138 Characteristic indicators:

Functions of DSO138:

 1.It features automatic, conventional and single-trigger modes, facilitating the capture of instantaneous waveforms

 2. It can be triggered by rising or falling edges

 3. The trigger level position is adjustable and comes with an indication

 4. Observable waveform before triggering (negative delay)

 5. Waveform display can be frozen at any time (HOLD function)

 6. It is equipped with a 1KHz /3.3V square wave test signal source
